• Wheels, 18" (45.7 cm) forged polished aluminum includes 18" x 8" (45.7 cm x 20.3 cm) steel spare wheel. (Requires single rear wheels.)
• Tires, LT265/70R18E all-season, blackwall (Requires single rear wheels.)
• Wheel, 18" x 8" (45.7 cm x 20.3 cm) full-size, steel spare Spare not included with (ZW9) pickup box delete unless a spare tire is ordered. (Requires 18" wheels and tires and single rear wheels. Included with (E63) Pickup Box. Available to order when (ZW9) pick-up box delete is ordered.)
• Wheelhouse liners, rear (Not available with dual rear wheels.)
• Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door
• Bumper, front, body-color
• Bumper, rear body-color with bumper CornerSteps
• CornerStep, rear bumper
• LPO, Assist steps, chromed tubular, 6" rectangular (dealer-installed) (May be substituted with (VXJ) assist steps, LPO. (VXH) is deleted when (VXJ) assist steps, LPO is specified.)
• Moldings, bodyside, chrome
• Headlamps, halogen projector with LED signature
• Fog lamps, front, halogen
• Lamps, cargo area, cab mounted with switch on center switch bank
• LED Lighting, cargo box with switch on center switch bank
• Mirrors, outside heated power-adjustable vertical camper, manual-folding and extending, black. Includes integrated turn signal indicators consisting of 50 square inch flat mirror surface positioned over a 20 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable).
• Glass, deep-tinted
• Window, power, rear sliding with rear defogger (Not included when (VYU) Snow Plow Prep Package is ordered.)
• Door handles, chrome
• Tailgate and bed rail protection caps, top
• Tailgate, locking, utilizes same key as ignition and door (Deleted with (ZW9) pickup box delete.)
• Tailgate, EZ-Lift and Lower (Deleted when (ZW9) pickup box delete is ordered.)
• Cargo ties downs (4), movable upper (Deleted when (ZW9) pickup box delete is ordered.)

• Audio system, 8" Diagonal Color Touch Screen Navigation with IntelliLink, AM/FM/SiriusXM with USB ports, auxiliary jack, SD card slot, Bluetooth® streaming audio for music and most phones, hands-free smartphone integration, Pandora Internet radio and voice-activated technology for radio and phone
• Single-slot CD/MP3 player (Replaced by (U42) rear seat DVD/Blu-Ray Entertainment Package when (U42) is ordered.)
• SiriusXM Satellite Radio and HD Radio SiriusXM Satellite Radio includes a 3-month trial. (If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call 1-866-635-2349 to cancel. See SiriusXM Customer Agreement for complete terms at siriusxm.com. Other fees and taxes will apply. All fees and programming subject to change. IMPORTANT: The SiriusXM Satellite Radio trial package is not provided on vehicles that are ordered for Fleet Daily Rental ("FDR") use.)
• Bose Sound with 6 speaker system (7 speaker system including subwoofer when ordered with bucket seats).
• Bluetooth® for phone personal cell phone connectivity to vehicle audio system

• Seats, front full-feature leather-appointed bucket with (KA1) heated seat cushions and seat backs. Includes 10-way power driver and front passenger seat adjusters, including 2-way power lumbar control, 2-position driver memory, adjustable head restraints, (D07) floor console and storage pockets.
• Seat trim, Leather-appointed front seats
• Seating, heated and cooled perforated leather-appointed front bucket
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
• Console, floor mounted, reconfigurable with moveable cup holders, cell phone storage, power cord management and hanging file holder capability
• Floor covering, color-keyed carpeting mats (include second row floor mats)
• Floor mats, color-keyed carpeted first and second row
• Steering column, manual Tilt-Wheel and telescoping
• Steering wheel, heated, leather wrapped with audio and cruise controls
• Steering wheel audio controls
• Display, enhanced driver instrument information , 8" multi-color configurable
• Windows, power with driver express up and down and express down on all other windows
• Door locks, power
• Remote Keyless Entry
• Remote vehicle starter system
• Pedals, power-adjustable
• Cruise control, steering wheel-mounted
• Universal Home Remote (Not included when (VYU) Snow Plow Prep Package is ordered.)
• Theft-deterrent system, unauthorized entry
• Air conditioning, dual-zone automatic climate control
• Defogger, rear-window electric
• Power outlet, 110-volt AC
• Mirror, inside rearview auto-dimming
• Visors, driver and front passenger illuminated vanity mirrors
• Assist handle, front passenger and driver on A-pillars

• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control includes electronic trailer sway control and hill start assist
• Daytime Running Lamps with automatic exterior lamp control
• Air bags, single-stage frontal and thorax side-impact, driver and front passenger, and head curtain side-impact, front and rear outboard seating positions (Required with (C7A) 10,000 lb. (4536 kg) GVWR. Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Air bags, frontal, driver and right front passenger, single stage
• OnStar, 6 months of Directions and Connections plan (Visit onstar.com for coverage map, details and system limitations. Services vary by model and conditions.)
• Front and Rear Park Assist, Ultrasonic
• Rear Vision Camera with dynamic guide lines

DURAMAX PLUS PACKAGE

• includes (LML) Duramax 6.6L Turbo Diesel V8 engine
• (MW7) Allison 1000 6-speed automatic transmission and (Y65) Driver Alert Package

ENGINE, DURAMAX 6.6L TURBO DIESEL V8, B20-DIESEL COMPATIBLE

• (397 hp [296.0 kW] @ 3000 rpm
• 765 lb-ft of torque [1032.8 N-m] @ 1600 rpm)

TRANSMISSION, ALLISON 1000 6-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED

• with overdrive
• electronic engine grade braking and tow/haul mode

DENALI PREFERRED EQUIPMENT GROUP

• includes standard equipment

AUDIO SYSTEM, 8" DIAGONAL COLOR TOUCH SCREEN NAVIGATION WITH INTELLILINK, AM/FM/SIRIUSXM

• with USB ports
• auxiliary jack
• SD card slot
• Bluetooth® streaming audio for music and most phones
• hands-free smartphone integration
• Pandora Internet radio and voice-activated technology for radio and phone

TIRES, LT265/70R18E ALL-SEASON, BLACKWALL

• (STD)

SEATS, FRONT FULL-FEATURE LEATHER-APPOINTED BUCKET WITH (KA1) HEATED SEAT CUSHIONS AND SEAT BACKS.

• Includes 10-way power driver and front passenger seat adjusters
• including 2-way power lumbar control
• 2-position driver memory
• adjustable head restraints
• (D07) floor console and storage pockets. (STD)

WHEELS, 18" (45.7 CM) FORGED POLISHED ALUMINUM

• includes 18" x 8" (45.7 cm x 20.3 cm) steel spare wheel. (STD)

LAMPS, SMOKED AMBER ROOF MARKER

• (required with dual rear wheels)

SUSPENSION PACKAGE, STANDARD

• includes 51mm twin tube shock absorbers and 33mm front stabilizer bar (STD)

PICKUP BOX, WIDESIDE

• (STD)

WHEELS, 17" (45.7 CM) FORGED POLISHED ALUMINUM

• includes 17" steel spare wheel. Spare not included with (ZW9) pickup box delete unless a spare tire is ordered.

WHEEL, 17" X 6.5" (43.2 CM X 16.5 CM) FULL-SIZE, STEEL SPARE

• Spare not included with (ZW9) pickup box delete unless a spare tire is ordered.

LPO, ASSIST STEPS, CHROMED TUBULAR, 6" RECTANGULAR

• (dealer-installed)

• 3.73 Rear Axle Ratio
• Cocoa/Dune
• Engine Block Heater
• Exhaust Brake
• Federal Emissions Requirements
• Floor Mounted Console
• High Idle Switch
• Smoked Amber Roof Marker Lamps
• Standard Suspension Package
• Summit White
• Driver Alert Package
• Duramax Plus Package
• Preferred Equipment Group 5SA
• 110-Volt AC Power Outlet
• 12V power outlets 4 12V power outlets
• 150 Amps Alternator
• 3-point seatbelt Rear seat center 3-point seatbelt
• 4-Wheel Disc Brakes
• 4WD type Part-time 4WD
• 7 Speakers
• 8' Enhanced Driver Instrument Information Display
• ABS brakes
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Four channel ABS brakes
• Accessory power Retained accessory power
• Adjustable pedals
• Adjustable pedals Power adjustable pedals
• Air Conditioning
• Air conditioning Yes
• Alloy wheels
• Alternator Type Alternator
• AM/FM radio: SiriusXM
• Amplifier
• Antenna Fixed audio antenna
• App Link Smart device integration Smart device app link
• Armrests front center Front seat center armrest
• Armrests rear Rear seat center armrest
• Audio theft deterrent Audio system theft deterrent
• Auto door locks Auto-locking doors
• Auto headlights Auto on/off headlight control
• Auto-Dimming Inside Rear-View Mirror
• Auto-dimming Rear-View mirror
• Automatic temperature control
• Aux input jack Auxiliary input jack
• Auxiliary power take-off
• Basic warranty 36 month/36,000 miles
• Battery charge warning
• Battery run down protection
• Battery type Dual lead acid batteries
• Bed liner Spray-in pickup bed liner
• Bed-rail protectors Pickup bed-rail protectors
• Bedliner
• Beverage holders Front beverage holders
• Beverage holders rear Rear beverage holders
• Block heater Engine block heater
• Body panels Galvanized steel/aluminum body panels with side impact beams
• Bodyside moldings
• Bodyside moldings Chrome bodyside moldings
• Bose Speaker System
• Box style Standard style pickup box
• Brake assist
• Brake assist system
• Brake type DuraLife 4-wheel disc brakes
• Bumper rub strip front Chrome front bumper rub strip
• Bumpers front Body-colored front bumper
• Bumpers rear Body-colored rear bumper
• Bumpers: body-color
• Cab mounted cargo light
• Cabback insulator
• CD location CD player located in the dashboard/instrument panel
• CD player
• CD Single-disc CD player
• CD-R compatible
• Child door locks Manual rear child safety door locks
• Chrome Bodyside Moldings
• Chrome Door Handles
• Chrome Power-Adjustable Heated Outside Mirrors
• Clearance lights Cab clearance lights
• Climate control Automatic climate control
• Clock Digital clock
• Color-Keyed Carpeted 1st & 2nd Row Floor Mats
• Color-Keyed Carpeting Floor Covering
• Compass
• Compressor Intercooled turbo
• Console insert material Simulated wood and metal-look console insert
• Convex spotter Driver and passenger convex spotter mirrors
• Cooled front seats Ventilated driver and front passenger seats
• Corrosion perforation warranty 72 month/100,000 miles
• Cruise control Cruise control with steering wheel mounted controls
• Cylinder head material Aluminum cylinder head
• Day/Night rearview mirror
• Deep-Tinted Glass
• Delay off headlights Delay-off headlights
• Delay-off headlights
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door bins rear Rear door bins
• Door handle material Chrome door handles
• Door locks Power door locks with 2 stage unlocking
• Door mirror style Chrome door mirrors
• Door mirror type Manual extendable trailer mirrors
• Door mirrors Power door mirrors
• Door panel insert Simulated wood door panel insert
• Drive type Four-wheel drive
• Driver & Front Passenger Visors
• Driver door bin
• Driver foot rest
• Driver information center
• Driver lumbar Driver seat with 4-way power lumbar
• Driver seat direction Driver seat with 8-way directional controls
• Driver vanity mirror
• Dual front impact airbags
• Dual front side impact airbags
• Dual-Zone Automatic Climate Control
• Dual-zone front climate control
• Easy lift tailgate EZ Lift
• Easy lower tailgate EZ Lower
• Electric Rear-Window Defogger
• Electronic Shift Transfer Case
• Electronic Stability Control
• Electronic stability control Electronic stability control system with anti-roll
• Emergency communication system: OnStar Directions & Connections
• Emergency SOS Capable OnStar Directions & Connections vehicle integrated emergency SOS system
• Engine block material Iron engine block
• Engine Configuration Duramax V8
• Engine cooler Engine oil cooler
• Engine Duramax 6.6L V-8 diesel direct injection, intercooled turbo, diesel, engine with 397HP
• Engine hour meter
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine retarder Engine retarder system
• Engine Short Duramax 6.6L V-8
• Engine temperature warning
• Engine/electric motor temperature gauge
• Exterior mirror spot lights Exterior mirror LED spot lights
• Exterior Parking Camera Rear
• External memory IntelliLink external memory control
• EZ-Lift & Lower Tailgate
• First-row windows Power first-row windows
• Floor console Full floor console
• Floor console storage Covered floor console storage
• Floor coverage Full floor coverage
• Floor covering Full carpet floor covering
• Floor mats Carpet front and rear floor mats
• Fog lights Front fog lights
• Folding door mirrors Power folding door mirrors
• Folding rear seats 60-40 folding rear seats
• Forward collision warning Forward Collision Alert
• Front anti-roll bar
• Front anti-roll Front anti-roll bar
• Front Body-Color Bumper
• Front Bucket Seats
• Front Center Armrest
• Front dual zone A/C
• Front fog lights
• Front Frame-Mounted Black Recovery Hooks
• Front Full Feature Bucket Seats
• Front Halogen Fog Lamps
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front impact airbag driver Driver front impact airbag
• Front impact airbag passenger Passenger front impact airbag
• Front passenger lumbar Front passenger seat with 4-way power lumbar
• Front reading lights
• Front seat upholstery Leather front seat upholstery
• Front seatback upholstery Plastic front seatback upholstery
• Front side impact airbag driver Seat mounted side impact driver airbag
• Front side impact airbag passenger Seat mounted side impact front passenger airbag
• Front wheel independent suspension
• Fuel Type Diesel
• Fully automatic headlights
• Garage door opener
• Garage door transmitter
• Gearshifter material Urethane gear shifter material
• Glove box Locking glove box
• Grille style Chrome grille
• Handsfree Bluetooth® handsfree wireless device connectivity
• Headlight type Projector beam headlights
• Headlights Halogen headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Heated & Cooled Driver & Front Passenger Seats
• Heated door mirrors
• Heated door mirrors Heated driver and passenger side door mirrors
• Heated Driver & Front Passenger Seats
• Heated front seats
• Heated front seats Heated driver and front passenger seats
• Heated steering wheel
• Height adjustable seatbelts Front height adjustable seatbelts
• High mount stop light High mounted center stop light
• Hill start assist
• Ignition Compression ignition system
• Ignition type Mechanical
• Illuminated entry
• Immobilizer
• In-box lighting LED in-box lighting
• Instrumentation display Analog instrumentation display
• Integrated navigation Integrated navigation system with voice activation
• Interior 120V AC power outlets 1 interior 120V AC power outlet
• Interior accents Chrome interior accents
• Interior courtesy lights Fade interior courtesy lights
• Internet access OnStar 4G LTE mobile hotspot internet access
• Internet radio capability Pandora internet radio capability
• Key in vehicle warning
• Keyfob keyless entry
• Keyfob remote start
• Lane departure Lane departure warning
• Leather Wrapped Heated Steering Wheel
• Lock-up transmission
• Locking hub control Auto locking hub control
• Low level warnings Low level warning for coolant, fuel, washer fluid, brake fluid and diesel exhaust fluid (DEF)
• Maintenance warranty 24 month/24,000 miles
• Manual Tilt-Wheel/Telescoping Steering Column
• Memory seat
• Memory settings Memory settings include: door mirrors and pedals
• Navigation System
• Number of airbags 6 airbags
• Number of doors 4 doors
• Number of first-row screens 2 total number of 1st row displays
• Number of memory settings 2 memory settings
• Occupancy sensor Airbag occupancy sensor
• Occupant sensing airbag
• Oil pressure gauge
• Oil pressure warning
• One-touch down window Front and rear one-touch down windows
• One-touch up window Driver one-touch up window
• OnStar 6 Months Directions/Connections
• OnStar w/4G LTE
• Outside temperature display
• Overdrive transmission
• Overhead airbag
• Overhead airbags Curtain first and second-row overhead airbags
• Overhead console
• Overhead console Mini overhead console
• Overhead console storage
• Paint Non-metallic paint
• Panel insert Simulated wood and metal-look instrument panel insert
• Panic alarm
• Parking sensors UltraSonic front and rear parking sensors
• Passenger door bin
• Passenger doors rear left Conventional left rear passenger door
• Passenger doors rear right Conventional right rear passenger door
• Passenger seat direction Front passenger seat with 8-way directional controls
• Passenger vanity mirror
• Pedal memory
• Perforated Leather-Appointed Seat Trim
• Perimeter approach lighting Remote activated perimeter approach lighting
• Power Adjustable Pedals
• Power door mirrors
• Power driver seat
• Power driver seat controls Driver seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power passenger seat
• Power passenger seat controls Passenger seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power Sliding Rear Window
• Power steering
• Power Windows
• Powertrain type ICE
• Powertrain warranty 60 month/100,000 miles
• Primary display size 8 inch primary display
• Primary display touchscreen Primary monitor touchscreen
• PTO transmission provision
• Radiator
• Radio AM/FM/SiriusXMsatellite
• Radio: AM/FM Stereo w/8' Diagonal Color Touch Nav.
• Rear 60/40 Folding Bench Seat (Folds Up)
• Rear Body-Color Bumper w/Bumper CornerSteps
• Rear bumper step
• Rear camera Rear mounted camera
• Rear cargo door Tailgate
• Rear console climate control ducts
• Rear head restraint control 2 rear seat head restraints
• Rear head restraint control Manual rear seat head restraint control
• Rear head restraints Height adjustable rear seat head restraints
• Rear locking differential Automatic rear locking differential
• Rear reading lights
• Rear seat center armrest
• Rear seat direction Front facing rear seat
• Rear seat folding position Fold-up rear seat cushion
• Rear seat upholstery Vinyl rear seat upholstery
• Rear seatback upholstery Carpet rear seatback upholstery
• Rear seats fixed or removable Fixed rear seats
• Rear seats Split-bench rear seat
• Rear Springs Regular grade rear springs
• Rear step bumper
• Rear under seat ducts Rear under seat climate control ducts
• Rear Vision Camera w/Dynamic Guide Lines
• Rear window defroster
• Rear windshield Power rear windshield
• Rearview mirror Auto-dimming rear view mirror
• Remote Keyless Entry
• Remote panic alarm
• Remote Vehicle Starter System
• Roadside warranty 60 month/100,000 miles
• Running lights LED daytime running lights
• Satellite trial 3 month satellite trial subscription
• Seatback storage pockets 2 seatback storage pockets
• Seatbelt pretensioners Front seatbelt pretensioners
• Seatbelt pretensioners number 2 seatbelt pre-tensioners
• Seating capacity 5
• Second-row windows Power second-row windows
• Security system
• Seek scan
• Selectable mode transmission Tow/Haul Mode selectable mode transmission
• Service interval warning Service interval indicator
• Shock absorbers Gas-pressurized shock absorbers
• Side steps Side assist steps
• Single-Slot CD/MP3 Player
• SiriusXM Satellite Radio
• Skid plate 2 underbody skid plates
• Spare tire Full-size spare tire with steel wheel
• Spare tire location Crank-down spare tire
• Speakers Bose speakers
• Speakers number 7 speakers
• Special paint Monotone paint
• Speed control
• Speed sensitive volume
• Split folding rear seat
• Split front seats Bucket front seats
• Springs front Front coil springs
• Springs rear Rear leaf springs
• Steering Hydraulic power-assist steering system
• Steering mounted audio control Steering wheel mounted audio controls
• Steering type Re-circulating ball steering
• Steering Wheel Audio Controls
• Steering wheel material Leather and metal-look steering wheel
• Steering wheel mounted audio controls
• Steering wheel telescopic Manual telescopic steering wheel
• Steering wheel tilt Manual tilting steering wheel
• Suspension Heavy-duty ride suspension
• Suspension ride type front Independent front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension type front Torsion beam front suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailgate control Manual tailgate/rear door lock
• Tailpipe Stainless steel single exhaust
• Telescoping steering wheel
• Temperature display Exterior temperature display
• Tilt steering wheel
• Tinted windows Deep tinted windows
• Tires LT265/70SR18 AS BSW front and rear tires
• Tow hooks front 2 front tow hooks
• Towing brake controller Trailer brake controller
• Towing class Class IV tow rating
• Towing hitch Trailer hitch
• Towing trailer sway Trailer sway control
• Towing wiring harness Trailer wiring harness
• Traction control
• Traction control All-speed ABS and driveline traction control
• Trailering Equipment
• Transfer case Electronic transfer case shift
• Transmission Allison 6-speed automatic
• Transmission electronic control
• Transmission fluid temperature warning Transmission fluid temp warning
• Transmission oil cooler
• Transmission Type Automatic
• Trip computer
• Trip odometer
• Turn signal in door mirrors Turn signal indicator in door mirrors
• Turn signal indicator mirrors
• Turn signal warning Turn signal on warning
• Turn-by-turn nav OnStar Turn-by-Turn Navigation
• Two-Speed Transfer Case
• Ultrasonic Front & Rear Park Assist
• Unauthorized Entry Theft-Deterrent System
• Universal Home Remote
• Variable panel light Variable instrument panel light
• Variably intermittent wipers
• Vehicle tracker OnStar Directions & Connections vehicle tracker with vehicle slowdown
• Ventilated brakes Front and rear ventilated disc brakes
• Ventilated front seats
• Visor driver mirror Driver visor mirror
• Visor illuminated driver mirror Illuminated driver visor mirror
• Visor illuminated passenger mirror Illuminated passenger visor mirror
• Visor passenger mirror Passenger visor mirror
• Voice activated audio IntelliLink voice activated audio controls
• Voltmeter
• Wheels 18 x 8-inch front and rear chrome aluminum wheels
• Window Trim Chrome side window trim
• Wipers Variable intermittent front windshield wipers
• Wireless streaming Bluetooth® wireless audio streaming

• Electrical
• Cold Cranking Amps @ 0° F (Primary): - TBD -
• Maximum Alternator Capacity (amps): 150
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Rear (lbs): 7050
• Curb Weight - Front (lbs): 4652
• Curb Weight - Front (lbs): 3930
• Curb Weight - Rear (lbs): 3000
• Curb Weight - Rear (lbs): 2962
• Gross Vehicle Weight Rating Cap (lbs): 13025
• Gross Vehicle Weight Rating Cap (lbs): 11000
• Gross Combined Wt Rating (lbs): 24500
• Gross Combined Wt Rating (lbs): 20500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 16900
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 13700
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1690
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1370
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 16900
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 13700
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4225
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3425
• Maximum Trailering Capacity (lbs): 22600
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Multi-Leaf
• Spring Capacity - Front (lbs): 5600
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 7050
• Axle Type - Front: Independent
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 5600
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 7050
• Axle Ratio (:1) - Rear: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 51.00
• Shock Absorber Diameter - Rear (mm): 51.00
• Stabilizer Bar Diameter - Front (in): 1.31
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): - TBD -
• Rear Brake Rotor Diam x Thickness (in): - TBD -
• Tires
• Front Tire Order Code: QQO
• Front Tire Order Code: QWF
• Rear Tire Order Code: QQO
• Rear Tire Order Code: QWF
• Spare Tire Order Code: ZQO
• Spare Tire Order Code: ZWF
• Front Tire Size: LT235/80R17E
• Front Tire Size: LT265/70R18E
• Rear Tire Size: LT235/80R17E
• Rear Tire Size: LT265/70R18E
• Spare Tire Size: LT235/80R17E
• Spare Tire Size: LT265/70R18E
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 6.5
• Front Wheel Size (in): 18 x 8.0
• Rear Wheel Size (in): 17 x 6.5
• Rear Wheel Size (in): 18 x 8.0
• Spare Wheel Size (in): 17 x 6.5
• Spare Wheel Size (in): 18 x 8.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 16.00
• Steering Ratio (:1), At Lock: N/A
• Turning Diameter - Curb to Curb (ft): 56.1
• Turning Diameter - Wall to Wall (ft): N/A
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 36.0
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 167.70
• Length, Overall w/o rear bumper (in): 258.4
• Width, Max w/o mirrors (in): 80.51
• Height, Overall (in): 78.07
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 151.10
• Cab to Axle (in): 55.24
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 39.41
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 8.53
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.76
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 51.02
• Cargo Box (Area) Height (in): 21.22
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 76.3
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 42.80
• Front Leg Room (in): 45.27
• Front Shoulder Room (in): 64.84
• Front Hip Room (in): 60.73
• Second Head Room (in): 40.50
• Second Leg Room (in): 40.93
• Second Shoulder Room (in): 64.33
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: GMC Sierra 3500HD
• Body Style: Crew Cab Pickup
• Body Code: E63
